Quick Details

  • Place of Origin: Jiangsu, China (Mainland)
  • Grade: 6000 Series, 6000series
  • Temper: T3-T8
  • Application: Decorations
  • Shape: U
  • Alloy Or Not: Is Alloy
  • Model Number: ST
  • Brand Name: Jia Duoli
  • Color: silver,black etc
  • Surface Treatment: anodized,power coating etc
  • Certificate: ISO9001:2008; ISO14001:2004; SGS
  • Height:: 50-320mm
  • Aluminum type: High quality anodized
  • Dimensions:: 50-320mm
  • Width:: 37-115mm
  • Thickness:: 4.5-11mm
  • Name: anodized silver aluminum U channel profiles

Packaging & Delivery

Packaging Details EP Film, crate box, wooden pallet, or plywood case. As a rule for anodized aluminum u channel profiles , 12 tons for a 20GP; 24 tons for a 40GP
Delivery Time Shipped in 7 days after payment

 Favourable price with highest quality



 OEM&OGM is also welcomed

Product Description

1.Name:anodized aluminum u channel profiles



2.Item:aluminum extrusions profiles for led strips



3.Material:6063,6061,6060,6005 etc



4.Temper:T5,T6



5.Color:Silver,Black,Red,Blue,White,and many other colors can be available



6.Specifications;As customers requirement



7.Fabrication:cutting,drilling,punching,milling,deburring,clearing,etc



8.Package:inner plastic paper interleaving each profile,outer fixed by plywood or pallets, or as required.



9.Certification:ISO 9001:2008;ISO14001:2004;SGS



10.Moulding:our mould,no fee;if opening,usually 10-50 tons for free



Technical Data

 1)Chemical composition for anodized aluminum u channel profiles

Alloy   Si   Fe    Cu  Mn    Mg      Cr  Zn  Ti impurity  Al
6063  0.2  0.35    0.1 0.10.45-0.9     0.1  0.1 0.1  0.15Rest
6061 0.4-0.8  0.70.15-0.4 0.150.8-1.20.04-0.35 0.250.15  0.15Rest
6060 0.3-0.60.1-0.3    0.1 0.10.35-0.6       - 0.15 0.1  0.15Rest
6005 0.6-0.9  0.35    0.1 0.10.4-0.6     0.1  0.1 0.1  0.15Rest

2)Mechanical property  for anodized aluminum u channel profiles

     Alloy  Temper     Tensile strength    Yield strength   Elongation
     6063      T5         ≥160Mpa       ≥110Mpa      ≥8%
      T6         ≥205Mpa       ≥180Mpa      ≥8%
     6061      T6         ≥265Mpa       ≥245Mpa      ≥8%

3)Anodized  for anodized aluminum u channel profiles

   Grade

                   Anodizing thicknessHole scaling quality of oxide layer
  Average  thickness  Local  thicknessP.Cr erosion weight less method
   AA10      ≥10um     ≥8um

          ≤30mg/d m²

   AA15      ≥15um     ≥12um

4)Powder coating  for anodized aluminum u channel profiles

Coating thicknessCoating impress rigidityAdhesive force of coating layer
40-120mmIndentation hardness>80              0 Grade







Packaging & Shipping





EXW wuxi or FOB Shanghai

Lead time: samples 3days, order 7-10days.

MOQ100 kg.

Payment : T/T, L/C

Recommend DHL, UPS , Fedex to express sample and small orders less than 200kgs, and Sea way for bulk quantities.
